HA02-12V battery equalizer is used for 12V lead-acid battery or lifepo4 battery which is connected in series to keep battery voltage balance.

(Gel/Flood/AGM lead-acid batteries alll are ok) When 4 connected batteries are in charging/discharging/free status. The battery voltage may become

different. One battery voltage is high and one is low. The battery equalizer will balance the voltage among batteries when it detects there are 20mV

between 2 batteries.It will shunt current from one battery with higher voltage to the other batteries with lower voltage.Until their voltage almost

becomes the same. This will improve battery's performance and extent battery's life time.



HA02-6S battery equalizer is for balancing 8*2-12V battery bank. Compatible with lead acid battery, lifepo4 battery, NiMH Battery, etc. It start work when there is 10mv voltage difference between batteries.

  • Model: HA02-6S
  • Battery: 6 x 2-12V battery
  • Size: 190*66*23mm
  • IP67 Waterproof
  • Weight: 0.7kg
  • CE RoHS Certification





HA02-16S battery equalizer is for balancing 8*2-12V battery bank. Compatible with lead acid battery, lifepo4 battery, NiMH Battery, etc. It start work when there is 10mv voltage difference between batteries.

  • Model: HA02-16S
  • Battery: 16 x 2-12V battery
  • Size: 489 * 66*23mm
  • IP67 Waterproof
  • Weight: 1.8kg
  • CE RoHS Certification





HA02-8S Battery equalizer is for balancing 8*2-12V battery bank. Compatible with lead acid battery, lifepo4 battery, NiMH Battery, etc. It start work when there is 10mv voltage difference between batteries.

  • Model: HA02-8S
  • Battery: 8 x 2-12V battery
  • Size: 248 * 66*23mm
  • IP67 Waterproof
  • Weight: 0.8kg
  • CE RoHS Certification





HA11L Battery equalizer is for balancing 2*12V battery bank. Compatible with lead acid battery, lifepo4 battery, NiMH Battery, etc. It start work when there is 20mv voltage difference between batteries.

  • Model: HA11L
  • Battery: 2*12V battery
  • With display show realtime voltage
  • Size: 70*70*27mm
  • Weight: 0.2KG
  • CE RoHS certification







HA02 battery equalizer is for balancing 4*2-12V battery bank. Compatible with lead acid battery, lifepo4 battery, NiMH Battery, etc. It start work when there is 10mv voltage difference between batteries.

  • Model: HA02
  • Battery: 4 x 2-12V battery
  • Size: 124 * 62*27mm
  • IP67 Waterproof
  • Weight: 0.4kg
  • CE RoHS Certification





HA12L battery equalizer is for balancing 4*2-12V battery bank. Compatible with lead acid battery, lifepo4 battery, NiMH Battery, etc. It start work when there is 10mv voltage difference between batteries.

  • Model: HA12L
  • Battery: 4 x 6-12V battery
  • With display show realtime voltage
  • Size: 124*62*27mm
  • IP67 Waterproof
  • Weight: 0.4kg
  • CE RoHS Certification





HA01 battery equalizer is for balancing 2*12V battery bank. Compatible with lead acid battery, lifepo4 battery, NiMH Battery, etc. It start work when there is 20mv voltage difference between batteries.

  • Model: HA01
  • Battery: 2*12V battery
  • With inside LED light
  • Size: 70*70*27mm
  • Weight: 0.18KG
  • CE RoHS certification





HA11 battery equalizer is for balancing 2*12V battery bank. Compatible with lead acid battery, lifepo4 battery, NiMH Battery, etc. It start work when there is 20mv voltage difference between batteries.

  • Model: HA11
  • Battery: 2*12V battery
  • With Bluetooth
  • Size: 70*70*27mm
  • Weight: 0.25KG
  • CE RoHS Certification
